Red Wayfarer H9 (hub-drive crossbar)
Red Wayfarer H9 (hub-drive crossbar)
Wisper Front Rack
50Nm Hub Drive at the hub


Wayfarer H9 Hub-Drive Crossbar

(1 customer review)

£1,749.00£2,198.00 inc VAT

From £60.50 Per Month*

Clear
SKU: H9 Hub-Drive-Crossbar Categories: , , , ,

Description

Crossbar Hub-Drive (H9): City, Adventure, Mountain

The Wisper Wayfarer H9 mid drive, crossbar is the perfect all-rounder. In City spec it is a comfortable commuter or day to day workhorse but underneath the city exterior beats the heart of a true thoroughbred, the Wayfarer super hi torque motor developing 50Nm at the rear wheel, almost the same as 100Nm at the pedals. Strip off the comfort products and change the tyres and you have the perfect off-roader for a day in the hills and forests. If you require further assistance, please do not hesitate to contact us.

Technical Specification

Motor

Wisper Hi Torque Rear Hub Drive 43.2V 250W Nominal

Lithium Battery

In frame, secure removable. Chargeable in or out of frame
On/off button with LED charge status light.
Standard 450Wh
Long range 700Wh

Assisted range

Total load, terrain, road surface, tyre pressures, speed, power setting, wind conditions and motor power all have a huge bearing on an eBike’s bikes range. With this in mind, you may expect to achieve the following AVERAGE ranges. Due to the number of outside factors affecting all electric bikes, our published ranges are estimates only, based on our experience and are not guaranteed.
450Wh battery 20 – 40 miles (30 – 60km)
700Wh battery 30 – 60 miles (50 – 100km)

Controls

Wisper Back lit LCD display with remote controls
Thumb throttle to 4mph (6km/h) walk along
Thumb throttle to 15.5mph (25km/h) assist booster

Bicycle weight

450Wh: 26kg
700Wh: 28kg

Frame

Hand welded, 6061 Alloy T4 and T6 tempered

Frame size

18” 46cm

Frame Colour

Pillar Box Red or Sky Blue 6 coats

Forks

Suntour XCM 30 100mm travel

Bars

eMTB 760mm anodised black

Sizing and Dimensions

Saddle

Wisper Comfort, eBike with seat handle

Kick stand

Black anodised alloy

Gears

Shimano Altus 8 speed with Rapid Fire shifter

Chain

KMC X8 rust resist 8 speed

Chain drive

Prowheel 48t

Freewheel

13 to 34

Brakes

Wisper Apex Hydraulic disc brakes, 2.5 finger F180mm R160mm

Wheels

Alloy black anodised double wall 27.5” x 1.24″ (31.4mm)

Tyres

Kenda 27.5” 2.2 high puncture resistance with reflector

MTB/Adventure Bike Tyre Upgrade (optional extra)
Schwalbe Smart Sam Perf, DD, RaceGuard, Folding 27.5” x 2.25” First class all-rounder with extra safe Double Defence puncture protection 3mm GreenGuard layer, SnakeSkin sidewall. ECE-R75 approved for great riding fun on your E-Mountain or E-Adventure Bike. Wayfarer rims can take tyres of up to 2.25″ wide without fouling forks or frame. Tyres larger than 2.25″ wide can only be used without mudguards.

Mudguards

Black Anodised Aluminium 2.6″

Lighting

Front: Spaningo XE 6V powered from bike battery
Rear: Spaningo XE 6V powered from bike battery

Stem

Magix black anodised 70mm

Seat post

31.6mm 350mm with 100mm safety line

Rear Rack

Wisper integrated custom, 17kg limit

Front Rack (optional extra)

Wisper integrated custom, 10kg limit

Max Weight Load Inc. Luggage
21st 135kg

eCity, eAdventure or eMountain?

The Wisper Wayfarer… a New Concept

The Wisper Wayfarer a first in the cycling industry.  The Wayfarer has been designed from the wheels up as a 27.5″ eMountain Bike.  Mountain bikes are comfortable, safe, strong and easy to ride.  We added strong anchor points for a chain guard, kick stand, luggage racks and our purpose built extra wide, tough aluminium mudguards.  We then made a second frame without the crossbar, offering riders a step-through e-bike with eMTB DNA.

The Wayfarer offers three distinct riding styles based on the same frame.

Wayfarer City

Perfect for commuters, shoppers and those that want leisurely rides in the country.  We utilise all the anchor points, adding front and rear mudguards, a rear rack and kick stand. For comfort, low noise and low rolling resistance we fit Kenda Town and Country tyres suitable for metaled roads and well made tracks.

Wayfarer Adventure

Built for the more adventurous. We fit Schwalbe Smart Sam Performance, DD, RaceGuard, 27.5” x 2.25” tyres with extra safe Double Defence puncture protection that fit neatly under the existing wide Aluminium mudguards. Ready for more adventurous away from the road riding.  Perfect for the hills and dales with huge grip and control in the dust, gravel, grass and mud.

Wayfarer Mountain

Completely stripped back but fitted with Schwalbe Smart Sam Performance, DD, RaceGuard, 27.5” x 2.25” tyres with extra safe Double Defence puncture protection so there is nothing to get in the way of an exhilarating day in the hills.

Mid Drive or Rear Hub Drive?

Although very different, neither one is better than the other. The choice though is very important and will change from person to person depending on where the bike is to be ridden and your riding style.  IMPORTANT: 50Nm measured at the hub is almost exactly the same as 100Nm measured at the crank axle. Both motors have the same power 250W nominal.

100Nm Mid Drive puts the power through the bike gears giving the rider better hill climbing capability

50Nm Hub drives the wheel directly, it’s more efficient and does not cause wear to the gears and chain

Specify your new Wisper Wayfarer in very much the same way as you would a new car…

  1. Choose a frame? Step through or Crossbar (Step through – product code 7.  Crossbar – product code 9.)
  2. Choose a motor? 50Nm Hub Drive or 100Nm Mid Drive (Hub drive – product code H.  Mid Drive – product code M.)
  3. Choose a battery 450Wh standard range or 700Wh long range
  4. Choose a colour Iridium Silver is only available on Mid Drive bikes. Deep Red or Deep Blue are only available on Hub Drive bikes
  5. Choose a style CityAdventure or Mountain (Mountain riding is not recommended with the step through frame)
  6. Choose whether you would like a Front Rack fitted to your bike

From these six simple choices you can create your own “bespoke” Wisper Wayfarer.

Some examples…

Wayfarer City M9 (Mid Drive, Crossbar)

27.5″ 2.2″ High Puncture Resistance Kenda Town and Country Tyres
Alloy mudguards with cable management
Rear rack
Large LCD centre display

You can at any time convert your City bike to an Adventure or Mountain bike

Wayfarer Adventure M9 (Mid Drive, Crossbar)

Schwalbe Smart Sam Performance, DD, RaceGuard, 27.5” x 2.25” tyres with extra safe Double Defence puncture protection
Large LCD centre display. Wayfarer rims can take tyres of up to 2.6″ wide without fouling forks or frame. Tyres larger than 2.25″ wide can only be used without mudguards.
Alloy mudguards with cable management
Rear rack
Large LCD centre display

Wayfarer Mountain M9 (Mid Drive, Crossbar)

Schwalbe Smart Sam Performance, DD, RaceGuard, 27.5” x 2.25” tyres with extra safe Double Defence puncture protection
Large LCD centre display. Wayfarer rims can take tyres of up to 2.6″ wide without fouling forks or frame. Tyres larger than 2.25″ wide can only be used without mudguards. No mudguards, chain guard, side stand or rack fitted. (We will include a set just in case you decide you need them in the future!)

Wisper Wayfarer M9 Cross Bar in Iridium Silver with Mid Motor and Mountain Pack
Wisper Wayfarer M9 Cross Bar in Iridium Silver with Mid Motor and Mountain Pack
Wayfarer M7 mid-drive step-through

Wayfarer M7 City (Mid Drive, Step Through)

Wisper Wayfarer M7 Step Through in Iridium Silver with Mid Motor and City Pack

Wayfarer M9 Mountain (Mid Drive Crossbar)

Wayfarer M7 Adventure (Mid Drive, Step Through)

Wisper Wayfarer M7 Step Through in Iridium Silver with Mid Motor and City Pack Side view

Wayfarer H9 City (Rear Hub Drive, Crossbar, Front Basket)

Red Wayfarer H9 Hub-drive crossbar Ebike with Rack

Wayfarer H7 City (Mid Drive, Step Through)

Blue Wayfarer H9 Hub-drive crossbar Ebike

Pricing

Wisper Wayfarer step through or Crossbar version

H7 and H9 with rear hub drive £1,699.00
M7 and M9 with mid drive £2,499.00

Factory fitted extras

City Pack £0
Mountain Pack £50.00
Adventure Pack £50.00
700Wh long range battery £250
Front basket £99.00
